English更多PG56S-PM-ST系列產品請致電0519-88385510或郵件info@ht-motor.com
| 外殼材質 | Housing Material | 粉末冶金 |
| 輸出軸承形式 | Bearing at output | 滾珠軸承 |
| 徑向負載 | Radial load (10mm from flange) | ≤250(N) |
| 軸向負載 | Shaft axial load | ≤100(N) |
| 靜態主軸最大承受壓入力 | Shaft press fit force max Static | ≤1000(N) |
| 徑向間隙 | Radial play of shaft | ≤0.08(mm) |
| 軸向間隙 | Thrust play of shaft | ≤0.5(mm) |
| 背隙（無負載時） | Backlash at no-load | ≤2.5° |
*負載與轉速有關，具體數據需參考實際情況。
*Load relates to speed, actual value depends on different situation.
| 減速比 | 額定允許負載（Nm） | 瞬間允許負載（Nm） | 效率（%） | 長度 | 重量 | 減速比級數 |
|---|---|---|---|---|---|---|
| 1:3.6 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:4.25 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:5.33 | 10 | 30 | 90% | 48 | 430 | 1 |
| 1:12.96 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:15.3 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:18.06 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:19.2 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:22.67 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:28.44 | 20 | 50 | 81% | 60 | 570 | 2 |
| 1:46.66 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:55.08 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:65.03 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:69.12 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:76.77 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:81.6 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:96.33 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:102.4 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:120.89 | 40 | 70 | 72% | 72 | 710 | 3 |
| 1:151.70 | 40 | 70 | 72% | 72 | 710 | 3 |
